THERMALTAKE ToughLiquid Ultra 360 360mm CPU Liquid Cooler
MPN THERMALTAKE-TOUGHLIQUID-ULTRA-360 · Brand Thermaltake
Features of THERMALTAKE ToughLiquid Ultra 360 360mm CPU Liquid Cooler TOUGHLIQUID Ultra 360 AIO Cooler is an all-in-one liquid cooler with our latest LCD display that presents real-time information of the system and even plays GIF files with 480*480 resolution. It’s also equipped with TOUGHFAN 12 Turbo fans to provide outstanding cooling results while maintaining minimal audible noise. 2.1 Inch Rotational LCD Display A 2.1 Inch Rotational LCS Display tha t presents real-time information and even
Inclusive of GST · GST invoice available
Overview
Features of THERMALTAKE ToughLiquid Ultra 360 360mm CPU Liquid Cooler
TOUGHLIQUID Ultra 360 AIO Cooler is an all-in-one liquid cooler with our latest LCD display that presents real-time information of the system and even plays GIF files with 480*480 resolution. It’s also equipped with TOUGHFAN 12 Turbo fans to provide outstanding cooling results while maintaining minimal audible noise.
2.1 Inch Rotational LCD Display
A 2.1 Inch Rotational LCS Display that presents real-time information and even play JPG and GIF files with 480*480 resolution, bringing great visual aesthetics and highly customizable functions to your All-in-One cooler.
TOUGHFAN 12 Turbo Equipped
Equipped with three TOUGHFAN 12 Turbo fans, the TOUGHLIQUID Ultra 360 boosts the fan speed up to 2500 RPM, ensuring the best cooling results whether you’re working or gaming.
High-Performance Cold Plate
The high-performance copper base plate accelerates heat conductivity. The high-quality and reliable pump enables maximum water circulation, keeping the copper plate continuously cool. The low evaporation tube effectively decreases the loss of coolant; therefore, no refill is required.
Fully Customizable with TT RGB Plus 2.0
Monitor frequency and real-time temperature directly from our 2.1 inch LCD Display, and upload any image or GIF file to add extra flair with the TT RGB Plus 2.0 software.
Caution: The TOUGHLIQUID Ultra Series is only supported by the TT RGB Plus 2.0.
TT RGB PLUS 2.0 Software
The new version of Thermaltake’s TT RGB PLUS patented software, providing more lighting effects and PC monitoring functions.
Caution: TT RGB PLUS 2.0 and TT RGB PLUS 1.0 will overwrite one another; users can only install one version of TT RGB PLUS.
Sync with Razer Chroma Lighting
All Thermaltake TT RGB PLUS products are able to connect into the Razer Chroma ecosystem, Razer Synapse 3. Users can experience synchronized gaming and RGB lighting effects on their TT RGB PLUS liquid cooling system and Razer gaming gear!
Works with Amazon Alexa
All Thermaltake TT RGB PLUS products support Amazon Alexa Voice Service, allowing you to give voice commands to the Alexa-enabled devices.
TT AI Voice Control
Give you full control over the TT RGB PLUS products with your voice. “SyncALL, Say”Hello TT”.
Specifications of THERMALTAKE ToughLiquid Ultra 360 360mm CPU Liquid Cooler
| P/N | CL-W323-PL12GM-A |
| PUMP | Motor Speed: 3200 RPM Rated Voltage: 12 V Rated Current: 0.38A Power Input: 4.56 W |
| CPU DISPLAY | Rated Voltage: 5 V Power Input: 11.5 W Display Type: 2.1” TFT-LCD Display Resolution: 480x480 (RGB) px |
| DISPLAY SUPPORT | Interface: Micro USB to USB (9PIN) System Compatibility: Windows 7 / 8 / 8.1 / 10 |
| FAN | Dimension: 120 x 120 x 25 mm Speed: PWM 500~2500 R.P.M (2510-4PIN) Noise Level: 28.1 dB-A Power Input: 2.76 W (one fan) Rated Voltage: 12 V Rated Current: 0.23A (one fan) Max. Air Flow: 72.69 CFM (one fan) Max. Pressure: 3.78 mm-H2O (one fan) |
| TUBE | Length: 400 mm Material: Rubber |
| RADIATOR | Dimension: 395 x 120 x 27 mm Material: Aluminum |
| COMPATIBILITY | CPU Socket: Intel LGA 2066/20113/2011/1366/1200/1156/1155/1151/1150 AMD AM4/AM3+/AM3/AM2+/AM2/FM2/FM1 |
Datasheet
| Fan | Dimension : 120 x 120 x 25 mmSpeed : PWM 500~2500 R.P.M (2510-4PIN)Noise Level : 28.1 dB-APower Input : 2.76 W (one fan)Rated Voltage : 12 VRated Current : 0.23A (one fan)Max. Air Flow : 72.69 CFM (one fan)Max. Pressure : 3.78 mm-H2O (one fan) |
|---|---|
| P/N | CL-W323-PL12GM-A |
| Pump | Motor Speed : 3200 RPMRated Voltage : 12 VRated Current : 0.38APower Input : 4.56 W |
| Tube | Length : 400 mmMaterial : Rubber |
| Radiator | Dimension : 395 x 120 x 27 mmMaterial : Aluminum |
| CPU Display | Rated Voltage : 5 VPower Input : 11.5 WDisplay Type : 2.1” TFT-LCDDisplay Resolution : 480×480 (RGB) px |
| Compatibility | CPU Socket :Intel LGA 2066/20113/2011/1366/1200/1156/1155/1151/1150 AMD AM4/AM3+/AM3/AM2+/AM2/FM2/FM1 |
| Display Support | Interface : Micro USB to USB (9PIN)System Compatibility : Windows 7 / 8 / 8.1 / 10 |
