Thermaltake Toughpower GF3 1350 Watt Gold ATX 3.0 Fully Modular SMPS

The Thermaltake Toughpower GF3 1350W Gold is a fully modular ATX 3.0 power supply engineered for high-performance desktop builds that demand stable, clean power delivery. Built to Intel's ATX 3.0 specification, the GF3 1350W can sustain power excursions up to 200% of rated load, accommodating the dynamic transient requirements of modern graphics cards. Its native 16-pin (12VHPWR) PCIe connector delivers up to 600W to compatible PCIe 5.0 graphics cards without adapters, future-proofing your system for next-generation GPU platforms. At the heart of the GF3 1350W is a single high-amperage +12V rail, supported by LLC resonant conversion and DC-to-DC circuitry for outstanding voltage stability. All major rails maintain voltage regulation within ±3% — tighter than the Intel-mandated ±5%/−7% standard — while ripple noise across the +12V, +5V, and +3.3V rails is held below 30mV from 0% to 100% load. These design choices translate directly into reliable, long-term operation for CPUs, GPUs, and storage alike. Thermal management is handled by a 140mm hydraulic bearing fan controlled by a Smart Zero Fan circuit: the fan remains completely silent until system load exceeds 30%, then ramps quietly as thermal demand rises. Capacitors are rated 105°C Japanese units throughout, contributing to the unit's rated MTBF of 100,000 hours minimum. The fully modular cable system uses low-profile flat black cables, simplifying cable routing and improving airflow inside the chassis. The PSU carries an 80 PLUS Gold efficiency rating at 115 V AC input and holds an extensive safety certification portfolio. Verified Specifications: - Model: PS-TPD-1350FNFAGD-4 - Max Output Capacity: 1350W - Efficiency: 80 PLUS Gold (115 V AC input) - ATX Standard: ATX 3.0 - PCIe Connector: Native 16-pin 12VHPWR (up to 600W) - PCIe 6+2 Pin Connectors: 3 - SATA Connectors: 4 - Peripheral 4-Pin: 1 - Modular: Fully Modular - Cooling: 140mm (14cm) hydraulic bearing fan, Smart Zero Fan - Voltage Regulation: <±3% on +12V and +5V rails - Ripple Noise: 17ms at 100% full load - Power Factor Correction: Active PFC - Input Voltage: 100–240V~ - Input Frequency: 50–60Hz - Input Current: 16–8A - Operating Temperature: 0°C to +50°C - Dimensions (W×H×D): 150mm × 86mm × 160mm - Weight: 1.83 kg - Color: Black - MTBF: 100,000 hours minimum - Safety Certifications: CE, UKCA, cTUVus, TÜV, FCC, IC, BSMI, EAC, CB, S-Mark, BIS, KCC - Warranty: 10 Years
