ZOTAC Gaming GeForce RTX 5060 Ti Twin Edge OC 16GB Nvidia Graphic Card

The ZOTAC Gaming GeForce RTX 5060 Ti Twin Edge OC (model ZT-B50620H-10M) is a compact, factory-overclocked graphics card built on the NVIDIA Blackwell architecture. It ships with 16 GB of GDDR7 memory running at 28 Gbps across a 128-bit bus, giving mid-range gaming builds a meaningful bandwidth upgrade over previous generations. The card’s 4608 CUDA cores are clocked at a boost of 2602 MHz out of the box, delivering solid 1080p and 1440p performance in current titles without requiring manual tuning. The Twin Edge OC’s physical footprint is deliberately slim: at 220.5 mm × 120.25 mm × 41.6 mm it occupies just two slots and fits most small form factor (SFF) chassis with minimal effort. Power requirements are kept modest — a single 8-pin PCIe connector feeds the card, and ZOTAC recommends a 600 W power supply, while the card’s TDP sits at 180 W. Display connectivity is generous for its class: three DisplayPort 2.1b outputs (UHBR20, supporting up to 4K 480 Hz or 8K 165 Hz with DSC) sit alongside one HDMI 2.1b port (supporting 4K 480 Hz HDR or 8K 120 Hz HDR with DSC). Up to four monitors can be driven simultaneously via its Quad Display capability, and HDCP 2.3 is supported for protected content playback. On the software and feature side, the card supports NVIDIA DLSS 4 with Multi Frame Generation, full ray tracing via fourth-generation RT Cores, NVIDIA Reflex 2 with Frame Warp for competitive latency reduction, NVIDIA G-SYNC, and Microsoft DirectX 12 Ultimate. OpenGL 4.6 is also supported. The card connects over PCI Express 5.0 x8. Cooling is handled by ZOTAC’s IceStorm 2.0 system with dual BladeLink fans. A metal backplate adds structural rigidity. The card is compatible with Windows 11 and Windows 10 64-bit (version 1809 or later). ZOTAC’s FireStorm utility provides overclocking, fan-curve tuning, voltage monitoring, and White LED lighting control. Verified Specifications: • GPU: NVIDIA GeForce RTX 5060 Ti (ZT-B50620H-10M) • CUDA Cores: 4608 • Video Memory: 16 GB GDDR7 • Memory Bus: 128-bit • Memory Speed: 28 Gbps • Boost Clock: 2602 MHz • Interface: PCI Express 5.0 x8 • Display Outputs: 3× DisplayPort 2.1b (UHBR20), 1× HDMI 2.1b • Multi-Display: Quad Display • HDCP: 2.3 • Power Connector: 1× 8-pin PCIe • TDP: 180 W • Recommended PSU: 600 W • Slot Width: 2-slot • Card Dimensions: 220.5 mm × 120.25 mm × 41.6 mm • DirectX: 12 Ultimate | OpenGL: 4.6 • SLI: Not supported • OS Support: Windows 11 / Windows 10 64-bit (v1809+)
