AMD Ryzen 7 9850X3D 9th Generation Processor ( 5.6 GHz / 8 Cores / 16 Threads )

The AMD Ryzen 7 9850X3D is an enthusiast-grade desktop processor from AMD’s Ryzen 9000 series, built on the advanced Zen 5 microarchitecture. Manufactured using TSMC’s 4nm FinFET process for the CPU cores and TSMC’s 6nm FinFET process for the I/O die, this two-die package delivers a compelling balance of gaming performance and everyday productivity capability. At its core, the Ryzen 7 9850X3D features 8 CPU cores with simultaneous multithreading (SMT) enabled, yielding 16 logical threads for smooth multitasking. The base clock sits at 4.7 GHz, with AMD’s Precision Boost 2 technology capable of pushing individual cores up to 5.6 GHz under appropriate thermal and power conditions. With a 120W default TDP, the processor is designed for high-performance desktop builds — a liquid cooler is recommended for optimal sustained boost behaviour, as no cooler is included in the box. The cache hierarchy is one of this processor’s standout characteristics. The 9850X3D carries 640 KB of L1 cache, 8 MB of L2 cache, and a large 96 MB L3 cache — totalling 104 MB of combined cache — which helps reduce memory latency in cache-sensitive workloads such as gaming. Memory support is exclusively DDR5, with dual-channel operation and a maximum capacity of 192 GB (UDIMM). Official rated speeds reach DDR5-5600 in a two-DIMM configuration. ECC memory is supported, subject to motherboard validation. The processor connects to the rest of the system via AMD’s AM5 socket and is compatible with a wide range of chipsets including X870E, X870, X670E, X670, B850, B840, B650E, B650, and A620. Connectivity includes PCIe 5.0 with 28 total lanes (24 usable), four native USB 3.2 Gen 2 (10 Gbps) ports, one native USB 2.0 port, and NVMe support with RAID 0/1/5/10 configurations. USB Type-C DisplayPort Alternate Mode is also supported. Integrated graphics are provided by AMD Radeon Graphics (2 compute units, 2200 MHz), suitable for display output and basic tasks. The processor is unlocked for overclocking, supports AMD EXPO memory overclocking, Precision Boost Overdrive, and Curve Optimizer voltage offsets, with AMD Ryzen Master software providing desktop tuning control. Security features include AMD Secure Processor, Platform Secure Boot, firmware TPM, UEFI Secure Boot, AMD-V virtualisation, AMD-Vi I/O MMU, AMD AVIC, AMD Shadow Stack, AES-NI, and Virtualization-Based Security (VBS) support — covering both consumer and light workstation security requirements. Key Verified Specifications: – Architecture: Zen 5 | Codename: Granite Ridge AM5 – Cores / Threads: 8 / 16 – Base Clock: 4.7 GHz | Max Boost Clock: Up to 5.6 GHz – L1 Cache: 640 KB | L2 Cache: 8 MB | L3 Cache: 96 MB – TDP: 120W | Max Tjmax: 95°C – CPU Die Process: TSMC 4nm FinFET | I/O Die Process: TSMC 6nm FinFET – Socket: AM5 | Memory: DDR5 (dual-channel, up to DDR5-5600, max 192 GB) – PCIe Version: PCIe 5.0 | Usable PCIe Lanes: 24 – Integrated Graphics: AMD Radeon Graphics (2 CUs, 2200 MHz) – Overclocking: Unlocked | AMD EXPO: Yes | Cooler: Not included – OS Support: Windows 11/10 64-bit, RHEL x86 64-bit, Ubuntu x86 64-bit – Warranty: 3 Years – Product ID: 100-100001973WOF
