Cooler Master CMP 520 ATX Mid Tower Case

The Cooler Master CMP 520 is an ATX mid-tower PC case designed for builders who want striking visuals paired with practical thermal flexibility. Its defining feature is an asymmetrical mesh front panel inspired by natural crystal formations — the geometric, geode-style cutouts deliver ample airflow intake while the integrated mesh layer acts as a dust filter, helping to keep internal components clean over extended use. Three ARGB fans are pre-installed right out of the box: one CF120P ARGB and two CF120S ARGB units, all mounted at the front. These fans light up the interior and push cool air toward your CPU and GPU from the moment the system powers The tempered glass left side panel puts that lighting on full display, making your components the centrepiece of your setup. Builders planning future upgrades will appreciate the CMP 520's flexibility. The case supports up to six fans in total, with mounting positions across the front (up to three 120mm or two 140mm), top (up to two 120mm or two 140mm), and a single 120mm at the rear. Radiator compatibility is equally broad: a 280mm or 240mm radiator fits at the front, a 240mm fits at the top (with RAM height under 35mm), and a 120mm fits at the rear. A 161mm CPU cooler clearance accommodates most tower air coolers, while a 350mm GPU clearance (without front fans and radiator installed) suits current high-end graphics cards. Cable management is handled by an 18.5mm routing channel behind the motherboard tray, and a full PSU shroud with ventilation conceals the power supply area and wiring below, giving the build a clean, finished look. The PSU shroud supports both active and passive PSU configurations and accommodates ATX power supplies up to 160mm in length, bottom-mounted. Storage options include two combo 2.5-inch/3.5-inch bays and two dedicated 2.5-inch SSD bays, giving you capacity for up to four SSDs and two HDDs simultaneously. Dust filters are positioned at the top and bottom to reduce maintenance requirements. Verified Specifications: - Model: CP520-KGNN-S00 - Form Factor: Mid Tower - Motherboard Support: Mini-ITX, Micro-ATX, ATX - Dimensions (incl. protrusions): 439 x 204 x 463 mm - Volume: 43.34 L (excl. protrusions) - Expansion Slots: 7 - Pre-installed Fans: 3x ARGB (1x CF120P + 2x CF120S, front) - Max Fan Support: 6 - CPU Cooler Clearance: 161 mm - GPU Clearance: 350 mm (without front fans/radiator) - PSU Clearance: 160 mm - Front Radiator Support: 120 / 140 / 240 / 280 mm - Top Radiator Support: 120 / 240 mm (RAM height ≤ 35 mm) - Rear Radiator Support: 120 mm - I/O Panel: 1x USB 3.2 Gen 1 Type-A, 1x USB 2.0, 1x 3.5mm headset jack - Drive Bays: 2x combo 2.5"/3.5", 2x 2.5" dedicated - Exterior Material: Steel, Plastic - Side Panel: Tempered Glass (left) - Dust Filters: Top, Bottom - Cable Routing: 18.5 mm - Exterior Colour: Black - Warranty: 2 Years
