DEEPCOOL PL650D 650W ATX 3.0 80+ Bronze Non Modular Power Supply

The Deepcool PL650D is a 650-watt non-modular power supply built to the ATX 3.0 standard, making it a capable foundation for both current and next-generation desktop builds. Its compliance with ATX12V V3.0 means the unit can sustain transient power spikes of up to twice the total system power for 0.1 ms, which is critical when pairing with modern discrete graphics cards that have unpredictable instantaneous power demands. A native PCIe 5.0 12VHPWR connector is included and rated for up to 300 W, removing the need for any adapter when connecting the latest generation of graphics cards. The cable bundle also includes three PCIe connectors and two EPS connectors, so the unit supports both older and newer hardware configurations without compromise. The PL650D carries the 80 PLUS Bronze certification, confirming at least 85% efficiency at 50% load under standardised test conditions. Power conversion relies on an Active PFC plus DC-to-DC topology, which helps deliver clean, regulated voltage across all output rails and reduces harmonic distortion on the mains supply. Cooling is handled by a 120mm fan using a hydro bearing, a design that balances acoustic performance with longevity. The unit incorporates a comprehensive protection suite covering over-power, over-voltage, short-circuit, over-temperature, over-current, under-voltage, surge and inrush protection, and no-load operation. Hold-up time meets or exceeds 16 ms at full load, giving the system enough time to ride through brief power interruptions. The power good signal is issued within 100–150 ms of a valid input, and MTBF is rated at 100,000 hours. The chassis measures 150 × 140 × 86 mm (W × L × H), fitting standard ATX cases. The unit is certified under CE, FCC, CCC, RCM, EAC, TUV-RH, and ErP 2014, and meets WEEE, RoHS, and Prop 65 environmental requirements. Verified Specifications: - Form factor: ATX12V V3.0 - Rated output power: 650 W - Efficiency certification: 80 Plus Bronze (≥85% at 50% load) - Fan: 120mm hydro bearing - Topology: Active PFC + DC-to-DC - Capacitors: Electrolytic - Hold-up time: ≥16 ms (100% load) - Power good signal: 100–150 ms - Protection: OPP / OVP / SCP / OTP / OCP / UVP / SIP / NLO - Operating temperature: 0–40°C - MTBF: 100,000 hours - Dimensions: 150 × 140 × 86 mm (W × L × H) - Part number: R-PL650D-FC0B-IN - Regulatory: CE, FCC, CCC, RCM, EAC, TUV-RH, ErP 2014, WEEE, RoHS, Prop 65
