Gamdias Boreas M2-61L 120mm CPU Air Cooler with LCD Display
MPN BOREAS-M2-61L · Brand GAMDIAS
The GAMDIAS Boreas M2-61L is a 120mm single-tower CPU air cooler with a 4.3" IPS LCD display, six copper heat pipes, and broad Intel/AMD socket support including LGA1851 and AM5
Inclusive of GST · GST invoice available
Overview
The GAMDIAS Boreas M2-61L is a single-tower 120mm CPU air cooler that combines capable thermal performance with a standout 4.3-inch IPS LCD display, making it a practical choice for system builders who want both cooling efficiency and a degree of visual personalisation. The LCD panel carries a 272×480-pixel vertical resolution, sized for displaying real-time system statistics, uploaded images, or animated GIFs via GAMDIAS's ZEUS CAST software on a Windows PC. At the heart of its cooling stack are six copper heat pipes routed through an optimised convex copper base. The convex base geometry is designed to maximise contact area with the CPU integrated heat spreader, reducing thermal resistance at the interface. Heat is drawn up through the pipes and dispersed across enlarged aluminium fin stacks before being exhausted by the included fan. The bundled 120mm fan uses a hydraulic bearing and a 4-pin PWM connector, allowing the motherboard or a fan controller to modulate speed between 800 RPM and 2000 RPM depending on thermal load. At maximum speed the fan moves up to 80.83 CFM of air at a static pressure of 2.80 mmH2O, with noise output scaling between 10 dBA at low speed and 32 dBA at full speed. The cooler body measures 130 × 80 × 160 mm (W × D × H), and GAMDIAS states a 160 mm height clearance requirement — buyers should confirm chassis compatibility before purchase. Socket compatibility covers a wide range of Intel and AMD platforms: LGA 1851, 1700, 1200, 1155, 1156, 1150, and 1151 on the Intel side, plus AM5 and AM4 for AMD. The mounting hardware ships in the box, supporting tool-assisted installation across all listed sockets. The unit is powered at 12 V through a standard 4-pin PWM header, and connects the LCD module via a 9-pin USB header on the motherboard. Verified Specifications: • Fan size: 120 × 120 × 25 mm • Fan speed: 800–2000 RPM (±10%) • Airflow: 80.83 CFM • Static pressure: 2.80 mmH2O • Noise level: 10–32 dBA • Bearing type: Hydraulic • Heat pipes: 6 × copper • Fin material: Aluminium • Cooler dimensions: 130 × 80 × 160 mm • Display: 4.3" IPS, 272×480 px (vertical) • Connector: 4-pin PWM (fan) + 9-pin USB (LCD) • Rated voltage: 12 V • Socket support: LGA1851/1700/1200/1155/1156/1150/1151; AM5/AM4 • Warranty: 1 year
Datasheet
| Warranty | 1 Year |
|---|---|
| Note*** | Features, Price and Specifications are subject to change without notice. Images use for Representation Purpose Only |
| Fan Size | 120 mm |
| Cooling Type | AIR COOLER |
| Pwm Controller | YES |
| Socket Support | LGA1851,LGA1700,LGA1200,LGA1150,LGA1151,LGA1155,LGA1156,AM5,AM4 |
| Supported Cooler CPU Wise | intel i3,intel i5,intel i7,intel i9,Core ultra 5,Core ultra 7,Core ultra 9,AMD Ryzen 3,AMD Ryzen 5,AMD Ryzen 7,AMD Ryzen 9,AMD Threadripper |
