Gamdias Helios E1-600 SMPS

The GAMDIAS Helios E1-600 is a 600W non-modular ATX power supply built to deliver stable, efficient power for mainstream desktop PC builds. Conforming to the ATX12V v2.4 standard, it supports modern Intel C6/C7 power states, allowing compatible systems to achieve deeper idle power savings without compromising stability under load. The unit operates on a single AC input range of 220–240V at 6A and 47–63Hz, making it well-suited for the standard Indian power grid. Across its DC rails, it provides +3.3V, +5V, +12V, -12V, and +5VSB outputs, with the critical +12V rail rated at up to 486W maximum output — the primary resource for CPUs and discrete graphics cards. Efficiency is rated at up to 80%, meaning the unit converts at least four-fifths of drawn AC power into usable DC power under typical load conditions. Thermal management is handled via automatic fan speed optimisation: the internal fan adjusts its rotational speed according to internal temperature, reducing noise during light workloads while ramping up as heat increases. The stealth black finish keeps the exterior understated inside any chassis. For system protection, the Helios E1-600 incorporates Over Voltage Protection (OVP), Under Voltage Protection (UVP), Over Power Protection (OPP), and Short Circuit Protection (SCP), collectively guarding connected components against common electrical faults. The fixed cable set covers the full connector range needed for a typical mid-range build and ships with a 3-year manufacturer warranty. Verifiable Specifications: - Model: HELIOS E1-600 - Form Factor: ATX12V v2.4 - Total Output Power: 600W - +12V Rail Max Output: 486W - +3.3V / +5V Combined Max Output: 100W - -12V Max Output: 3.6W - +5VSB Max Output: 12.5W - Max Output Current: 16A - AC Input: 220–240V / 6A / 47–63Hz - DC Outputs: +3.3V, +5V, +12V, -12V, +5VSB - Efficiency: Up to 80% - Connectors: 1× 20+4-pin Main Power, 1× 4+4-pin CPU (EPS 620mm), 2× 6+2-pin PCIe, 5× SATA, 2× Molex (4-pin), 1× Floppy (4-pin) - Modular: Non-Modular - Protection: OVP, UVP, OPP, SCP - C6/C7 Power State Support: Yes - MB Sync: Not supported - DC-to-DC Conversion: No - Dimensions (L × W × H): 140 × 150 × 86 mm - Warranty: 3 Years
