Gigabyte H470M DS3H M-ATX Motherboard
MPN H470M-DS3H · Brand GIGABYTE · mATX
The GIGABYTE H470M DS3H is a Micro-ATX motherboard with the Intel H470 chipset, LGA1200 socket, dual-channel DDR4 up to 128 GB, dual M.2 NVMe slots, four display outputs, and RGB Fusion 2.0 — designed for 10th Gen Intel Core processors
Inclusive of GST · GST invoice available
Overview
The GIGABYTE H470M DS3H is a Micro-ATX form-factor motherboard built on the Intel H470 Express chipset and designed for Intel's LGA1200 socket. It supports 10th Generation Intel Core processors — including Core i9, Core i7, Core i5, Core i3, Pentium, and Celeron — making it a versatile platform for home, office, and enthusiast builds alike. Memory support spans four DDR4 DIMM slots in a dual-channel configuration, accommodating up to 128 GB of system memory. Core i9 and i7 processors unlock speeds up to DDR4-2933, while i5, i3, Pentium, and Celeron processors support up to DDR4-2666. The board also supports Extreme Memory Profile (XMP) modules and is compatible with ECC Un-buffered DIMMs operating in non-ECC mode. Storage flexibility is a highlight: two M.2 Socket 3 connectors allow for NVMe PCIe x4 SSDs, with one slot additionally supporting SATA-based M.2 drives. Six SATA 6 Gb/s ports round out the storage options, and RAID 0, 1, 5, and 10 configurations are supported. The board is also Intel Optane Memory Ready. Display output is handled by four integrated interfaces — D-Sub, DVI-D, HDMI 1.4 (up to 4096×2160 at 30 Hz), and DisplayPort 1.4 (up to 4096×2304 at 60 Hz) — ideal for multi-monitor productivity setups. Audio is delivered via a Realtek ALC887 codec supporting up to 7.1-channel High Definition Audio. Connectivity is comprehensive: Intel Gigabit Ethernet with cFosSpeed Internet Accelerator software handles wired networking, while the rear panel features a USB Type-C port with USB 3.2 Gen 1 support, three USB 3.2 Gen 1 Type-A ports, and two USB 2.0 ports. Internal headers extend USB and fan connectivity further. RGB Fusion 2.0 with addressable LED and standard RGB strip headers lets builders personalise lighting across multiple zones. Smart Fan 5 provides hybrid fan headers with FAN STOP capability and multiple temperature sensors for informed thermal management. Q-Flash Plus enables BIOS updates without a CPU, memory, or graphics card installed. The board ships with a 3-year manufacturer warranty and is compatible with Windows 10 64-bit. Key Verified Specifications: - Form Factor: Micro-ATX (24.4 cm x 24.4 cm) - Socket: LGA1200 - Chipset: Intel H470 Express - CPU Support: 10th Gen Intel Core i9 / i7 / i5 / i3 / Pentium / Celeron (LGA1200) - Memory: 4 x DDR4 DIMM, dual-channel, up to 128 GB; up to DDR4-2933 (i9/i7) or DDR4-2666 (i5/i3/Pentium/Celeron) - M.2: 2 x Socket 3 M-key (PCIe x4/x2 NVMe; one also supports SATA) - SATA: 6 x SATA 6 Gb/s; RAID 0/1/5/10 - Display: D-Sub, DVI-D, HDMI 1.4 (4K@30Hz), DisplayPort 1.4 (4K@60Hz) - Audio: Realtek ALC887, up to 7.1-channel HD Audio - LAN: Intel GbE (1000/100 Mbit) - USB (rear): 1 x USB Type-C 3.2 Gen 1, 3 x USB 3.2 Gen 1, 2 x USB 2.0 - Expansion: 1 x PCIe x16 (x16), 1 x PCIe x16 (x4), 2 x PCIe x1 (all PCIe 3.0) - RGB: RGB Fusion 2.0; 1 x addressable LED header, 1 x RGB LED header - BIOS: AMI UEFI, Q-Flash Plus - Warranty: 3 Years
Datasheet
| Memory Type | DDR4 |
|---|---|
| Warranty | 3 Years |
| Form Factor | mATX |
| Chipset | H470 |
| Socket | LGA1200 |
| CPU Type | 9th Gen,8th Gen |
| Max Memory | 128 GB |
| Memory Speed | up to 2933 |
| Platform | INTEL |
| Graphics Port | D-Sub, DVI-D, HDMI, DisplayPort |
| Memory Feature | Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for Extreme Memory Profile (XMP) memory modules |
| Expansion Slots | 1 x PCI Express x16 slot, running at x16 (PCIEX16) For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot. 1 x PCI Express x16 slot, running at x4 (PCIEX4) 2 x PCI Express x1 slots (All of the PCI Express slots conform to PCI Express 3.0 standard.) Supports up to ASPM L1.2 power management protocols |
| Channel Supported | Dual Channel |
| Back Panel I/O Ports | 1 x PS/2 keyboard/mouse port 1 x D-Sub port 1 x DVI-D port 1 x HDMI port 1 x DisplayPort 1 x USB Type-C port, with USB 3.2 Gen 1 support 3 x USB 3.2 Gen 1 ports 2 x USB 2.0/1.1 ports 1 x RJ-45 port 3 x audio jacks |
| Internal I/O Connector | 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header 3 x system fan headers 1 x addressable LED strip header 1 x RGB LED strip header 2 x M.2 Socket 3 connectors 6 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x USB 3.2 Gen 1 header 2 x USB 2.0/1.1 headers 2 x Thunderbolt™ add-in card connectors 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only) 1 x serial port header 1 x parallel port header 1 x Clear CMOS jumper 1 x Q-Flash Plus button |
