GIGABYTE H510M H DDR4 Intel Motherboard

The Gigabyte H510M H is a Micro ATX motherboard built on the Intel H510 Express Chipset, designed for LGA1200-socket processors spanning the 10th and 11th Generation Intel Core lineup. It accommodates 11th Gen Core i9, i7, and i5 CPUs as well as 10th Gen Core i9, i7, i5, i3, Pentium, and Celeron processors, making it a practical foundation for a wide range of budget to mid-range PC builds. The board features two DDR4 DIMM slots in a dual-channel configuration, supporting up to 64 GB of system memory (32 GB per slot). Memory speeds reach DDR4 3200 MHz with compatible 11th Gen processors and up to DDR4 2933 MHz with 10th Gen i9 and i7 CPUs. XMP profiles are also supported for straightforward memory tuning. For storage, a single M.2 Socket 3 (M-key) connector accommodates 2260, 2280, and 22110 form-factor drives using either SATA or PCIe 3.0 x4/x2 interfaces. Four SATA 6 Gb/s ports provide additional drive connectivity. Expansion is handled by one PCIe x16 slot (PCIe 4.0 with 11th Gen processors, PCIe 3.0 with 10th Gen) and one PCIe x1 slot (PCIe 3.0). Onboard video output includes one D-Sub port (max 1920×1200 @ 60 Hz) and one HDMI 1.4 port (max 4096×2160 @ 30 Hz, HDCP 2.3). Networking is handled by a Realtek GbE LAN chip delivering 1 Gbit/100 Mbit connectivity with an included bandwidth management utility. Audio is provided through a Realtek High Definition Audio CODEC supporting up to 7.1-channel output. USB connectivity includes four USB 3.2 Gen 1 ports (two rear, two via internal header) and six USB 2.0/1.1 ports (four rear, two via internal header). The rear I/O panel also carries a PS/2 keyboard/mouse combo port, D-Sub, HDMI, RJ-45, and three audio jacks. Power delivery uses a 6+2 phase digital VRM with low RDS MOSFETs and solid capacitors, fed by an 8-pin solid-pin ATX 12V connector. Gigabyte's Smart Fan 6 technology manages thermal output through fan headers that each support PWM and DC fans or water-cooling pumps at up to 24 W (12 V × 2 A), with up to seven programmable temperature/fan-speed control points and a complete fan-stop option. The board ships with an AMI UEFI BIOS (256 Mbit flash), an RGB LED strip header, a TPM header (GC-TPM2.0 SPI compatible), and the full Gigabyte App Center suite including @BIOS, EasyTune, Fast Boot, Game Boost, Q-Flash, Smart Backup, and System Information Viewer. Key Verified Specifications: - Socket: LGA1200 | Chipset: Intel H510 Express - Memory: 2 × DDR4 DIMM, dual-channel, up to 64 GB; DDR4-3200 (11th Gen) / DDR4-2933 (10th Gen i9/i7) / DDR4-2666 (10th Gen i5/i3/Pentium/Celeron); XMP supported - Storage: 1 × M.2 (PCIe 3.0 x4/x2 or SATA, types 2260/2280/22110); 4 × SATA 6 Gb/s - Expansion: 1 × PCIe x16 (PCIe 4.0 with 11th Gen / PCIe 3.0 with 10th Gen); 1 × PCIe x1 (PCIe 3.0) - Video: 1 × D-Sub (1920×1200 @ 60 Hz); 1 × HDMI 1.4 (4096×2160 @ 30 Hz) - LAN: Realtek GbE (1 Gbit/100 Mbit) - USB: 4 × USB 3.2 Gen 1; 6 × USB 2.0/1.1 - Audio: Realtek HD Audio CODEC, up to 7.1-channel - Form Factor: Micro ATX, 244 mm × 210 mm - Warranty: 3 Years
