GIGABYTE X570SI Aorus Pro AX DDR4 AMD Motherboard

The Gigabyte X570SI Aorus Pro AX is a Mini-ITX form-factor motherboard built on the AMD X570 chipset, designed for AMD Socket AM4 processors. It supports the full AMD Ryzen 2000 through Ryzen 5000 series lineup — including G-Series APUs — making it a versatile platform for compact, high-performance builds where every millimetre counts. At the heart of its power delivery is a Twin 8+2 Phase Digital VRM solution featuring 90A Smart Power Stage components. This robust configuration ensures stable, clean power to demanding Ryzen processors even under sustained workloads. Cooling is managed via groove-designed, multi-layered heatsinks over the chipset and an M.2 Thermal Guard III with heatpipe to keep NVMe drives operating at optimal temperatures. Storage is well-served with two M.2 Socket 3 connectors (type 2280): the CPU-connected M2A slot supports PCIe 4.0 x4 with Ryzen 5000 and 3000 Series CPUs, while the chipset-connected M2B slot also supports PCIe 4.0 x4 (Ryzen 5000/3000 Series). Both slots include thermal shielding. Four SATA 6 Gb/s ports add flexibility with RAID 0, 1, and 10 support. Connectivity is a standout feature in this compact board. Networking is handled by an Intel 2.5GbE LAN chip with cFosSpeed traffic-shaping software. Wireless is provided by Intel Wi-Fi 6 (802.11ax, 2.4/5 GHz, up to 2.4 Gbps on 160 MHz) with Bluetooth 5.2 on PCB rev. 1.0, and AMD Wi-Fi 6E (RZ608, 2.4/5/6 GHz) with Bluetooth 5.2 on PCB rev. 1.1. The rear I/O includes one USB 3.2 Gen 2 Type-C port, one USB 3.2 Gen 2 Type-A (red) port, and four USB 3.2 Gen 1 ports. Audio is powered by the Realtek ALC1220-VB codec alongside Nichicon audio capacitors, supporting 7.1-channel output and DTS:X Ultra. RGB Fusion 2.0 enables multi-zone addressable LED customisation via one ARGB header and one RGB LED strip header. Q-Flash Plus allows BIOS updates without a CPU, memory, or graphics card installed — a practical convenience during builds. Verified Specifications: - Form Factor: Mini-ITX, 17.0 cm × 17.0 cm - Socket: AMD AM4 - Chipset: AMD X570 - CPU Support: Ryzen 2000 / 2000G / 3000 / 3000G / 4000G / 5000 / 5000G Series - Memory: 2 × DDR4 DIMM, dual-channel, up to 64 GB (32 GB per DIMM); DDR4-2133 to DDR4-5100 (O.C.) depending on CPU; ECC and non-ECC unbuffered; XMP support - GPU Slot: 1 × PCIe x16 (PCIe 4.0 x16 with Ryzen 5000/3000 Series) - Storage: 2 × M.2 (PCIe 4.0/3.0 x4, SATA); 4 × SATA 6 Gb/s; RAID 0/1/10 - LAN: Intel 2.5GbE (2.5 Gbps / 1 Gbps / 100 Mbps) - Wireless (rev. 1.0): Intel Wi-Fi 6 AX200, 802.11ax, 2.4/5 GHz, BT 5.2 - Wireless (rev. 1.1): AMD RZ608 Wi-Fi 6E, 2.4/5/6 GHz, BT 5.2 - Audio: Realtek ALC1220-VB, 7.1-ch, DTS:X Ultra - Back Panel USB: 1 × USB 3.2 Gen 2 Type-C, 1 × USB 3.2 Gen 2 Type-A, 4 × USB 3.2 Gen 1 - Display Output (APU only): 1 × DisplayPort 1.4 (4096×2304@60 Hz), 2 × HDMI 2.1 (4096×2160@60 Hz) - BIOS: AMI UEFI, 256 Mbit flash, Q-Flash Plus - VRM: 8+2 Phase Digital, 90A Smart Power Stage - OS Support: Windows 10 64-bit (official)
