Hyte X50 Matcha E-ATX Mid Tower Case

The HYTE X50 in Matcha is a 63-litre E-ATX mid tower chassis built around a design philosophy that treats airflow, acoustics, and cable discipline as equally important priorities. At its core is a patent-pending louvered blade ventilation system on the side panel that breaks up exhaust impedance and simultaneously reinforces chassis rigidity — a structural benefit that most open-mesh panels sacrifice. The side window is a 4mm thick laminated acoustic glass panel with a shatter-resistant bonding layer, significantly reducing sound transmission compared to standard tempered glass while keeping the internals fully visible. Cooling headroom is generous. The Cold-Floor configuration places up to three 120mm extra-thick fans directly beneath the GPU, channelling fresh air straight to the hottest component in the system. The front panel accepts either three 120mm or three 140mm fans, the rear takes a single 120mm, and the side accommodates another three 120mm units — a total ceiling of ten fans. Radiator builders can fit a 360mm loop (up to 105mm thick) at the front, a 360mm loop (up to 70mm thick) on the side, or a 120mm unit at the rear, giving liquid-cooling configurations genuine flexibility. The structural PSU canopy keeps the power supply and cabling out of the main chamber, aided by integrated tie-down points and included velcro straps routed both inside and outside the chassis. CPU tower coolers up to 170mm clear without modification, and GPUs up to 430mm long and 160mm tall are supported. Storage options include two 2.5-inch drive bays and one 3.5-inch bay, complemented by seven full-size horizontal expansion slots. Front I/O is modern: one USB 3.2 Gen 2×2 Type-C port delivering up to 20 Gbps, two USB 3.2 Gen 1×1 Type-A ports, and a 3.5mm combo audio jack. A tactile mechanical power switch with LED indicator provides tactile feedback. Bottom and magnetic dust filters round out the maintenance story. Key Specifications: - Form Factor: E-ATX (up to 10.6″), ATX, Micro-ATX, Mini-ITX - Volume: 63 L - Dimensions: 485mm (H) × 510mm (L) × 255mm (W) - Chassis Material: 1mm steel, ABS - Side Window: 4mm laminated acoustic glass - Max GPU: 430mm length, 160mm height - Max CPU Cooler: 170mm - Max PSU: 223mm - Fan Support: Up to 10 × 120mm (side 3, front 3, bottom 3, rear 1) - Radiator Support: Up to 360mm front & side, 120mm rear - Storage: 2 × 2.5″, 1 × 3.5″ - Expansion Slots: 7 horizontal full-size - Front I/O: 1× USB 3.2 Gen 2×2 Type-C, 2× USB 3.2 Gen 1×1 Type-A, 3.5mm combo jack - Dust Filters: Bottom (magnetic) - Warranty: 4 years - Color: Matcha
