Gigabyte H610M K DDR4 M-ATX Motherboard

The GIGABYTE H610M K DDR4 is a Micro-ATX motherboard designed for Intel LGA1700 processors, offering solid everyday computing performance in a compact form factor. It is compatible with Intel Core 12th, 13th, and 14th generation processors, as well as Intel Pentium and Celeron series chips on the same socket, making it a versatile foundation for home, office, or entry-level workstation builds. Memory support is handled through two DDR4 DIMM slots running in dual-channel configuration, with speeds up to DDR4-3200 MT/s and a maximum capacity of 64 GB. The board supports non-ECC unbuffered modules in 1Rx8, 2Rx8, and 1Rx16 configurations, and also accommodates ECC unbuffered modules operating in non-ECC mode. XMP profiles are supported for users who wish to run memory at rated enthusiast speeds. For storage, the board includes one M.2 Socket 3 connector running at PCIe Gen 3 x4 (NVMe), enabling fast solid-state storage, alongside two SATA 6Gb/s connectors for traditional or additional drives. Expansion is provided by one PCIe 4.0 x16 slot for a discrete graphics card and one PCIe 3.0 x1 slot for peripheral add-in cards. The back panel delivers practical connectivity: one HDMI port for display output, two USB 3.2 Gen 1 ports, four USB 2.0/1.1 ports, one RJ-45 Gigabit Ethernet port, and three audio jacks backed by high-quality audio capacitors and an audio noise guard for cleaner sound. Gigabit LAN includes bandwidth management to help prioritise network traffic and reduce latency. Thermal management is handled by Smart Fan 6 technology, which uses multiple temperature sensors and hybrid fan headers with FAN STOP support, allowing fans to remain off entirely at low loads. The 8-pin ATX 12V solid-pin power connector provides stable power delivery under CPU load. A TPM header supports optional GC-TPM2.0 SPI modules for security-conscious deployments. The GIGABYTE APP Center provides a unified software interface for system monitoring and tuning. Anti-sulfur resistors protect board components in environments prone to corrosion. GIGABYTE backs this board with a 3-year warranty. Verified Specifications: - Socket: LGA1700 - Chipset: Intel H610 - Form Factor: Micro-ATX - CPU Compatibility: Intel Core 12th / 13th / 14th Gen, Pentium, Celeron - Memory: 2 x DDR4 DIMM, Dual Channel, up to DDR4-3200, max 64 GB - Storage: 1 x M.2 (PCIe Gen 3 x4 / NVMe), 2 x SATA 6Gb/s - Expansion: 1 x PCIe 4.0 x16, 1 x PCIe 3.0 x1 - Display Output: 1 x HDMI - USB (rear): 2 x USB 3.2 Gen 1, 4 x USB 2.0/1.1 - LAN: 1 x Gigabit Ethernet (RJ-45) - Audio: 3 x 3.5 mm audio jacks, audio noise guard - Warranty: 3 Years
